Tray Dryer

Name: Tray Dryer
Brand: S. K. Food Equipments Pvt Ltd.
Price: 175000 INR
Availability: InStock

Price 175000 INR/ Set

Get a Price/Quote

MOQ : 1 Set

Tray Dryer Specification

Type
Tray Dryer

Material
Mild Steel

Capacity
24/48/96/192 trays (models available)

Computerized
No

Automatic Grade
Semi-Automatic

Voltage
220-380 V

Frequency (MHz)
50 Hz

Preheating Plate Size
Standard as per model

Size
Customizable, standard models available

Width
Standard as per model

Weight
350-1200 kg (depending on model)

Dimension (L*W*H)
1770 x 1160 x 2100 mm (example for 24-tray model)

Control Panel
Digital Temperature Controller

Chamber Finish
Polished/Semi-gloss

Air Circulation
By Heavy Duty Blower

Insulation Thickness
100 mm (mineral wool)

Door Construction
Double Walled, Insulated

Tray Material
Stainless Steel 304

Heating Media
Electric / Steam / Gas

Power Consumption
6-18 kW (depending on capacity)

Tray Size
16 x 32 x 1.25 (approx.)

Blower Motor
0.5-2 HP

Number of Trays
24, 48, 96, 192

Temperature Range
Ambient to 150C

Application
Food, Pharmaceuticals, Chemicals, Dyestuff, Textile, etc.

Tray Dryer Trade Information

Minimum Order Quantity
1 Set

Supply Ability
5 Sets, , Per Month

Delivery Time
2-3 Week

About Tray Dryer

Specification

AC Blower Motor: 1.0 HP-02 Nos. (make. C.G)
Power: 12 KW
No of trey: 48 Trey
Material of trey: Aluminum
Electric Supply: 415 V 50 Hz 4 Wire

Specification

AC Motor	1.0 HP
Capacity	24 Trey
Material	Stainless Steel
Automation Grade	Automatic
Warranty	1 Year
Electricity Supply	415 V 50 Hz 4 Wire
Heating Media	Electric
Motor	1.0 HP
Country of Origin	Made in India
Heater	12 kW

Optimized Air Circulation System

Each tray dryer is equipped with a heavy duty blower that ensures uniform hot air distribution within the drying chamber. This system guarantees consistent drying performance across all trays, reducing process time and improving product quality. The dryer's double-walled, insulated design minimizes heat loss and enhances energy efficiency.

Customizable Capacity and Configuration

Choose from standard models featuring 24, 48, 96, or 192 trays, or customize dimensions, tray quantity, and chamber width to suit your operational needs. Flexible heating options using electric, steam, or gas give you control over process economics and compatibility with your existing infrastructure.

FAQ's of Tray Dryer:

Q: How does the tray dryer achieve consistent drying across all trays?

A: Consistent drying is accomplished by using a heavy duty blower that circulates hot air uniformly throughout the chamber. The double-walled, insulated construction also helps maintain a stable temperature, ensuring all trays receive equal heat exposure.

Q: What materials and industries are best suited for this tray dryer?

A: This tray dryer is versatile and ideal for food, pharmaceuticals, chemicals, dyestuff, and textile industries. It safely handles items needing controlled, hygienic drying, supported by its Stainless Steel 304 trays and digital temperature control.

Q: When should I opt for electric, steam, or gas heating?

A: The choice of heating media depends on your available resources and operational preferences. Electric heating is suitable for precise temperature regulation, steam is cost-effective with existing steam supply, and gas offers lower operational costs for high-volume drying.

Q: Where can the tray dryer be installed, and what power requirements are needed?

A: Install the tray dryer in well-ventilated, industrial environments with access to 220-380 V and 50 Hz power. Power consumption ranges from 6 to 18 kW, depending on dryer capacity and model.

Q: What is the process for operating the tray dryer?

A: Load materials onto the Stainless Steel trays, set desired temperature on the digital controller, and start the blower for air circulation. Monitor and adjust as needed, ensuring proper drying times based on material and required moisture levels.

Q: How does the digital temperature controller enhance usage and safety?

A: The digital temperature controller allows precise adjustment and monitoring of internal temperatures, reducing the risk of overheating and improving the reproducibility of drying results, which is crucial for quality control and safe operation.

Q: What are the benefits of using a tray dryer with thick mineral wool insulation?

A: Thick mineral wool insulation (minimum 100 mm) efficiently retains heat within the chamber, enhances energy savings, and protects external surfaces from becoming hot, contributing to both operator safety and lower energy costs.
